Product Details
- Size: 181*76*118*118（mm）
- Place of Origin: ZHEJIANG
- Brand Name: weida
- Model Number: 12V10AH
- Weight: 1.000 kg
B.Specification:
| Cells Per Unit | 6 |
| Voltag e Per Unit | 12 |
| C apacity | 100Ah@10hr-rate to 1.75 V per cell @25 °C |
| Weigh t | Approx. 30 Kg |
| Max. D ischarge Curren t | 500 A (5 sec) |
| Internal Resistance | Approx. 5 mΩ |
| Opera ting Temperatur e Range | Discharge: -20°C~60°C |
| Charge: | |
| Storage: -20°C~60°C | |
| Normal Operating Temperature Range | 25°C±5°C |
| Float charging Voltage | 13.6 to 13.8 VDC/unit Average at 25°C |
| Recommended Maximum Charging | |
| Current Limit | 30 A |
| Equalization and Cycle Service | 14.4 to 15.0 VDC/unit Average at 25 |
| Self D ischarge | SAKO batteries can be stored fo r more than 6 months |
| at 25°C.Please charge batteries before using.For | |
| higher tem perature, the time int erval will be shoter. | |
| Terminal | Terminal F5/F12 |
| Container Material | A.B.S. (UL94-HB) Flammability resistance of UL94-V1 |
| can be available upon request. |
C.Application:
- portable TV,VTR,tape recorders,radio,pc,word processors,terminals,measuring equipment,telephone sets
- light for news cameras
- children's toy riding cars
- emergency lighting
- ups system for computer back up
- off grid solar power and wind power installations
- large-scale mateur robotics
- remote sensors
- ice monitoring station
- recreational marine purpose
- cell phone towers
- bank system
- computer system
